HOIST AND COUNTERWEIGHT RT540E SERVICE MANUAL
5-14 Published 4-20-2015, Control # 502-01
Item Description
1 Counterweight
2 Pin Assembly
3 Capscrew
4Hex Nut
5Jam Nut
6Grill
7 Retaining Nut
8Flat Washer
9 Lock Washer
10 Capscrew
11 Lock Pin
6826
FIGURE 5-5
4
3
5
7, 8, 9, 10
2, 11
6
1
2, 11
3
4
5
4
5
Reference Only
