RT540E SERVICE MANUAL LUBRICATION
3
FIGURE 9-12
8
18
6
9
8
21
9
22
19
20
11
12
Item Description
1 Hoist Tension Springs
2 Boom Extension Pins, Clips
3 Boom Nose Pins, Clips
4 Hook Block/ Headache Ball
5 Boom Extension Hanger Hardware
6 Pivot Shaft
7 Hose Connections inside turntable
8
All Hardware, Clips, Pins, Hose Connections
not painted O/R Pins, Clips
9 O/R Hose Connections
10 Hookblock Tie Down Cable
11 O/R Pins, Clips
12 O/R Beam Wear Pad Adjustment Hardware
13 Turntable Bearing Fasteners
14 Entire underside of unit
15 Power Train Hardware inside compartment
16 Valve Bank
17 Hoist Hose Connections
18 Wire Rope
