Published 4-20-2015, Control # 502-01 2-53
RT540E SERVICE MANUAL HYDRAULIC SYSTEM
1
3
2
4
5
6
3
4
5
6
6719-2
6719-1
Hydraulic Schematic
FIGURE 2-27
1
2
Item Description
1
Port P - Pressure From Axle Lockout Port On
Outrigger Selector Valve
2 Port T - Tank
3 Pressure Reducing Valve
Item Description
4 Solenoid Valve
5 Port B - To Lockout Cylinder Pilot
7 Port P1 - To Lockout Cylinder
Reference Only
