Manitowoc Grove RT540E Service Maintenance Manual

HYDRAULIC SYSTEM RT540E SERVICE MANUAL
2-66 Published 4-20-2015, Control # 502-01
FIGURE 2-37
6732
3
8
4
6
2
9
17
10
5
5
11
18
1
13
14
15
16
17
7
12
19
20
Item Description
1 Barrel
2Piston
3 Head
4 Wear Ring
5 Setscrew
6O-ring
7 Backup Ring
8 Hydrolock Seal
9 Wear Ring
10 O-ring
Item Description
11 Backup Ring
12 Spacer
13 Piston
14 Spacer
15 Rod
16 Rod
17 Head
18 Wear Ring
19 Plug
20 Check Valve
Reference Only
