Manitowoc Grove RT880E User Manual

Grove Published 11-10-2014, Control # 524-00 6-13
RT880E SERVICE MANUAL SWING SYSTEM
6
FIGURE 6-6
1
2
3
4
10
6
7
11
12
6490-1, 6490-2
13
14
15
Item Description
1 Nut and Washer
2 Electric Swivel
3 Capscrew and Washer
4 Spacer Bushing
5 Frame Mounting Lugs
6
Hex Head Screw and Jam
Nut
7 Retainer Plate
8 Hydraulic Swivel
9 Mounting Bolts
10
Water and Hydraulic
Case
11 Turntable Base Plate
12 Carrier Top Plate
13
Bolt and Bolt Retainer
Plate
14
Tubing Clamp, Bolt,
Lockwasher, Flatwasher
15 Electric Swivel Harness
9
8
