HYDRAULIC SYSTEM RT880E SERVICE MANUAL
2-28 Published 11-10-2014, Control # 524-00
Outrigger Control Manifold Valve
Service Brake Dual Accumulator Charge Valve
6385-5
4
5
3
Item Description
3 Procedure B - Outrigger Pressures - Adjust - Step No. 1
& No. 3
4 Procedure B - Outrigger Pressures - Adjust - Step No. 2
5 Procedure C - Oil Cooler Motor Pressure - Adjust - Step
No. 2
FIGURE 2-12
FIGURE 2-13
7752-02
Item Description
1 Procedure D - Set Service Brake
Accumulator Charge Valve Limits - Check/
Adjust - Step No. 2
1
