HYDRAULIC SYSTEM RT880E SERVICE MANUAL
2-50 Published 11-10-2014, Control # 524-00
Telescope Foot Controller
34
21
24
13
7766-01
7766-02
FIGURE 2-25
Item Description
1 Telescope In
2 Pressure Port
Item Description
3 Telescope Out
4 Port To Tank
