Manitowoc Grove YB5515

GROVE Published 10-21-2010, Control# 198-04 5-7
5540F/YB5515 SERVICE MANUAL PREVENTATIVE MAINTENANCE
5
.
p0421
Steering Knuckle Lube Points (Rear Axle)
FIGURE 5-7
p0419
Steering Link Lube Points (Front Axle)
FIGURE 5-8
p0422
Steering Link Lube Points (Rear Axle)
FIGURE 5-9
p0418
Steering Cylinder Pivot Ends Lube Points (Front Axle)
FIGURE 5-10
p0420
Steering Cylinder Pivots Ends Lube Points (Rear Axle)
FIGURE 5-11
Reference Only
