PREVENTATIVE MAINTENANCE 5540F/YB5515 SERVICE MANUAL
5-8 Published 10-21-2010, Control# 198-04
p1643
Drive Shaft Lube Points (Front Axle)
FIGURE 5-12
p0401
Drive Shaft Lube Points (Rear Axle-Typical)
FIGURE 5-13
p0423
Rear Axle Pivot Lube Point
FIGURE 5-14
p0391
Drop Block Lube Point
FIGURE 5-15
p0315
Jib Head Sheave Lube Point (Typical)
FIGURE 5-16
p0392
Jib Boom Deflector Sheave Lube Point
FIGURE 5-17
Reference Only
