DKR Drive Controllers About this Documentation
DOK-DIAX03-DKR********-PR02-EN-P
Note: The following documentation is not required in its entirety for
the correct use of the drive controllers DKR.
Title Type of
Documentation
Document Typecode Part
Number
AC Drive Units in Hazardous Areas
(Expl. Protection)
Instructions for
Use
DOK-GENERL-ANTR*EXPLOS-ANxx-EN-P 266 304
AC Drive Units in Personnel Conveyor
Systems
Instructions for
Use
DOK-GENERL-ANTR*PERSON-Anxx-EN-P 266 305
Electromagnetic Compatibility (EMC)
in Drive and Control Systems
Project Planning
Manual
DOK-GENERL-EMV********-PRJ*-EN-P 259 814
DIAX03/04, ECODRIVE03
AC-Hauptantriebe mit 2AD- und ADF-
Motoren /
AC main drives with 2AD- and ADF-
motors
Auswahldaten /
Selection data
DOK-DRIVE*-MAIN*WZM***-AU01-MS-P 289 233
DIAX03 Plug-in modules for digital
intelligent drive controllers
Project Planning
Manual
DOK-DIAX03-PLUG*IN*MOD-PRxx-EN-P 275 155
DIAX03 AC Drives for Continuous
Operation (S1)
Selection data DOK-DIAX03-PRIN******-AUxx-EN-P 274 660
DIAX03/04, ECODRIVE03
AC-Hauptantriebe für Dauerbetrieb
(S1) /
AC-Drives for Continuous Operation
(S1)
Auswahldaten /
Selection lists
DOK-DRIVE*-PRINT******-AUxx-MS-P 288 730
Asynchronous Linear Motors LAF Selection Data
DIAX03 / DIAX04
DOK-MOTOR*-LAF********-AUxx-EN-P 277 353
DIAX03 ... Drive
configuration
DOK-DIAX03-xxxxxxxxx**-INxx-EN-P
⊕1
Indramat Internal Connection System
LWL - Handling
Application
Description
DOK-CONNEC-CABLE*LWL**-AWxx-EN-E 284 755
⊕1: You need this document in order to determine the drive configuration or
to specify the hardware configuration labelling of a DIAX03 drive
controller. It is part of a firmware box set.
x: The "x" is a replacement character.
Fig.: Supplementary documentation
