5-12 Planning the cabinet DKR Drive Controllers
DOK-DIAX03-DKR********-PR02-EN-P
DKR03
Unit dimensions
DIAX03 DKR 03
190 ± 0,5
380
air outlet
(as delivered)
air inlet
(as delivered)
210 ± 0,5
80
668
690
10
310
MBDKR3
H1
X4
X2
U5
U3
S2
U4
U1 U2
X9
1
6
1
7
X8
H2
S1
X3
X7
1
10
1
11
X3
air inlet
(option)
air outlet
(option)
Netz/Mains
L3
L2L1
Motor
A3A1 A2
B2B1
220 V
Steuerspannun
g
Aux.
Voltage
NLK
X5
X10
TM+ TM- BR 0VB
• • • • •
X6
390
all dimensions in mm
max.
55
Fig. 5-11: Unit dimensions DKR03
