DKR Drive Controllers Planning the cabinet 5-9
DOK-DIAX03-DKR********-PR02-EN-P
5.3 Dimension sheets
CAUTION
Damage to devices caused by wrong mounting
position!
⇒
In order to avoid damage to the devices caused by
wrong mounting position, only install the devices in
accordance with the indicated mounting positions.
Required distances for cooling with air from inside the cabinet
zMILKDKR
min.
160 mm
min.
160 mm
air outlet
air inlet
DIAX03 DKR0 3
H1
X4
X2
U5
U3
S2
U4
U1 U2
X9
1
6
1
7
X8
H2
S1
X3
X7
1
10
1
11
X3
Netz/Mains
L3
L2L1
Motor
A3A1 A2
B2B1
220 V
Steuerspannun
g
Aux.
Voltage
NLK
X5
X10
TM+
TM-
BR
0VB
•
•
•
•
•
X6
Fig. 5-8: Required distances for cooling with air from inside the cabinet
