5-16 Planning the cabinet DKR Drive Controllers
DOK-DIAX03-DKR********-PR02-EN-P
DZB01
Unit dimensions
free space
440
460
480
6,5
200
200100
INDRAMAT
Type
kW
?
Amp.
%ED bei 120s Spield.
W-Nr.
Nr.
Last
R1
R2
blower
+ -
50
50
90
130
Fig. 5-15: Unit dimensions DZB01
