5-18 Planning the cabinet DKR Drive Controllers
DOK-DIAX03-DKR********-PR02-EN-P
MZSDKR4
air inlet
duct Ø 125
part no.: 238354
(is not a part of
M2-RAC 2.2)
air outlet
min.260
bend
radius
min.
R=125
min.
125
113
173
150
mounting
clearance with
horizontal air inlet
mounting
clearance
with vertikal
air inlet
flange 2
flange I
flange 2
25
1
6
X9
1
7
X8
1
10
X7
1
11
X3X3
H2
S1
U1 U3
U4
U5
U2
S2
X4
X2
H1
mind. 365
156
closed mounting panel
(without vents)
DIAX03 DKR 04
Fig. 5-17: Additional dimensions when cooling with a duct - DKR04
Note: All parts required for mounting, including screws, gaskets,
flanges, ... are included in the mechanical accessories kit
M2-RAC 2.2.
The ducts are not included in the mechanical accessories kit
but Rexroth Indramat can also supply them upon request.
