DKR Drive Controllers Planning the cabinet 5-21
DOK-DIAX03-DKR********-PR02-EN-P
•
Maximum length of the motor cable is 75 meters
•
Maximum length of the feedback connection is 75 meters
CAUTION
Failure or malfunction caused by clamping
points or intermediate coupler units!
⇒
The maximum lengths do not apply to clamping
points and intermediate coupler units. In addition, the
following notes apply to the indicated lengths of the
leads.
Note: The lengths given apply to
•
direct connections between drive and motor (without
clamping points or intermediate coupler units),
•
ready-made cables and
•
an ambient temperature of 40 °C (per EN 60 204).
Note: For further details on the current loads of leads as dependent
upon ambient temperatures, please see Fig. 6-10.
Length of the leads
