Mariner 75 - Description; Models Not Equipped with Test Button (3 and 4 Cylinder)

3B-590-13645--2 1095 OIL INJECTION SYSTEM
Models Not Equipped With Test Button
(3 and 4 Cylinder)
DESCRIPTION
Self-test of the warning system is performed by
turning the ignition key to the “RUN” position. A
steady beep is indicative of an overheat condition. An
intermittent beep refers to a low oil condition. Both
overheat and low oil conditions are monitored by a
warning module mounted on the starboard side of the
engine block.
25939
a
a - Warning Module
51551
a
b
c
d
e
f
g
h
a - Powerhead Temperature Sensor
b - Warning Module
c - Terminal Block
d - Warning Horn
e - Ignition Switch
f - Engine Harness
g - Remote Control Harness
h - Low Oil Sensor
