1-190-13645--2 1095 GENERAL INFORMATION AND SPECIFICATIONS
General Specification
NOTE:
Other specification (torques, etc.) are listed in
the respective sections.
Model 70 Model 75 Model 80 Model 90
Horsepower 70 (52.2 kw) 75 (55.9 kw) 80 (59.6 kw) 90 (67.1 kw)
Idle RPM (in forward gear) 650 - 700
Full Throttle RPM Range 4750 - 5250 5000 - 5500
Piston Replacement 71.12 (1165.7cc)
Cylinder Bore 3.375 (85.7mm)
Stroke 2.65 (67.3mm)
Engine Type 3 Cylinder, 2 Cycle
Ignition Type C.D. Breakerless
Recommended Spark Plug
NGK-BUHW-2 or AC-V40 FFK or
Champion L78V
Inductor Plugs: NGK-BUZHW-2 or
Champion QL78V
Cylinder Firing Order 1-3-2
Recommended Power Trim Fluid
Quicksilver Power Trim & Steering Fluid or Automotive Transmission
Fluid (ATF) Type F, FA or Dexron II
Recommended Gasoline
Regular Leaded, Premium, Low-Lead and Lead-Free automotive gaso-
lines with a minimum pump posted octane rating of 86
Recommended Oil Quicksilver TC-WII or TC-W3 2-Cycle Outboard Oil
Engine Weight ELO
ELOPT
260 lbs.
280 lbs.
Fuel Tank Capacity
6.6 U.S. Gallons
(5 Imp. Gals.; 25 Liters)
Gear Housing Lubricant Capacity 22.5 fl. oz. (665.3ml)
Gasoline/Oil Ratio at Idle 80:1
Gasoline/Oil Ratio at W.O.T. 50:1
Gear Ratio 2.3:1
Oil Injection Tank Capacity
Tank Capacity 1 gal. (3.78 liter)
Maximum operation per tank
full of oil at W.O.T.
6 hours
Oil remaining when warning
buzzer sounds
1 qt. (.95 liter)
Operating time remaining at
wide open throttle when warn-
ing buzzer sounds
1 Hour
