GSW2 PLUS EXT
INSTALLATION MANUAL
Page 17
NOTE
Time control is used in next functions:
- CLIP
- DTMF
- Input alarms ( OD parameters )
8.2.5 Table of parameters
Name
Comment
OS1
Mode of operation for output 1
OS2
Mode of operation for output 2
OD1
Input 1 direct link to outputs
OD2
Input 2 direct link to outputs
OD3
GSM network problem direct link to outputs
OD4
NAC direct link to outputs
OP1
Invert control for output 1
OP2
Invert control for output 2
OTS1
Output 1 time control START
OTE1
Output 1 time control END
OTS2
Output 2 time control START
OTE2
Output 2 time control END
Table 5: Output management parameters
Example:
 Direct programming on the SIM card
GSW2 PLUS PROGRAMMING TABLE
Name
Number
Description
OS1
1
Bi-stable toggle mode
OS2
14
Mono-stable pulse mode ( 14s pulse )
OD1
1
Input 1 activates output 1
OD2
2
Input 2 activates output 2
OP1
1
Output 1 inverted
Table 6: Output management parameters example
 Remote programming by SMS
;OS1=1;OS2=14;OD1=1;OD2=2;OP1=1;
