MARS COMMERCE GSW2 PLUS 1000 - Clip - Caller ID; Table 17: DTMF Control Example

GSW2 PLUS EXT
INSTALLATION MANUAL
Page 30
NOTE
GSW2 PLUS must be in voice connection to support DTMF output control!
Example:
DTMF combination
Description
00
Deactivate ALL outputs
01
Activate ALL outputs
11
Activate output 1
20
Deactivate output 2
Table 17: DTMF control example
8.9 CLIP – CALLER ID
CLIP is used to provide the “free of charge” options to control the outputs.
8.9.1 CLPEN parameter
Parameter used to enable CLIP functionality.
8.9.2 CLPOU parameter
Parameter used to choose which output will be controlled by the CLIP functionality.
8.9.3 CLPI parameter
This parameter, if set, is a precondition for CLIP function to control the output. The input define by
the CLPI parameter must be active for CLIP function to control the output.
8.9.4 CLPNN parameter
Parameter is used to set the starting point for notification function. Notification function is used
when the user need to notify itself (TN1 to TN5 use LN7) that the CLP function was used to control
the output.
8.9.5 CLPNM parameter
Parameter is used to define how the notification function operate. Notification function can send
SMS with the number controlling the output or it can issue instant voice call.
- CLPNM=0 Notify the user by voice call
- CLPNM=1 Notify the user by sending SMS
