MARS COMMERCE GSW2 PLUS 1000 - Wiegand Interface; Table 18: CLIP Parameters; Table 19: CLIP Parameters Example

GSW2 PLUS EXT
INSTALLATION MANUAL
Page 31
8.9.6 CLP1 … CLP1000 parameter
Set of telephone number, which can control the output. The number not on CLP list is not able to
control the output using clip functionality.
8.9.7 Table of parameters
Name
Comment
CLPEN
Enable CLIP functionality
CLPOU
Control output pin when CLIP event
CLPI
CLIP input activation condition
CLPNN
Notification number start
CLPNM
Notification function mode
CLP1
CLIP number 1
.
.
.
.
.
.
CLP1000
CLIP number 1000
Table 18: CLIP parameters
Example:
 Direct programming on the SIM card
GSW2 PLUS PROGRAMMING TABLE
Name
Number
Description
CLPEN
1
Enable CLIP functionality
CLPOU
2
CLIP control output 2
CLPI
0
No input activation condition
CLP1
040414414
CLIP number 1
CLP2
042340880
CLIP number 2
CLPNN
10
Output control action from the number CLP10 to CLP1000 will
be reported to TNx numbers ( use LN7 to define the links)
CLPNM
1
Notification is done with the SMS
Table 19: CLIP parameters example
 Remote programming by SMS
;CLPEN=1;CLPOU=2;CLPI=0;CLP1=040414414;CLP2=042340880;CLPNN=10;
;CLPNM=1;
8.10 WIEGAND INTERFACE
GSW2 PLUS device incorporates an output Wiegand interface, which is used to send CLIP number
information from GSW2 PLUS device to the Wiegand receiver (Access Control Terminal).
NOTE
For configuration, and protocol support please contact support.
