GSW2 PLUS EXT
INSTALLATION MANUAL
Page 32
8.11 DIRECT ACCESS BY ENTERING ACCESS CODE (VIA
WIEGAND CONNECTOR FROM 3
RD
PARTY WIEGAND
DEVICE)
The user may control the predefined outputs by entering the PIN access codes. PIN access code
from 1 to 500 (PIN1 to PIN500) will activate Output 1, PIN access codes from 501 to 1000
(PIN501 to PIN1000) will activate Output 2.
8.11.1 PIN1 to PIN1000
PINx parameters are the PIN access codes for controlling the outputs.
8.11.2 Table of parameters
Name
Comment
PIN1
PIN access code 1.
PIN2
PIN access code 2.
PIN3
PIN access code 3.
.
.
.
.
.
.
PIN998
PIN access code 998.
PIN999
PIN access code 999.
PIN1000
PIN access code 1000.
Table 20: Entering PIN code parameters.
Example:
 Direct programming on the SIM card
GSW2 PLUS ROGRAMMING TABLE
Name
Number
Description
PIN1
3369
PIN access code 1.
PIN122
1234
PIN access code 122.
Table 21: Entering PIN access code example.
 Remote programming by SMS
;PIN1 =3369;PIN122 =1234;
NOTE
PINx access codes must be from 4 to 10 digits long, and must start with number
greater or equal 1.
8.12 DIRECT ACCESS BY ENTERING TEMPORARY ACCESS
CODES – SPIN - VIA 3
RD
PARTY WIEGAND KEYPAD
The user may control the relay output by entering up to 50 temporary SPIN access codes which can
be determined how many times they will be used.
