ZEUS4-VD
INSTALLATION MANUAL
23
11.3 ADVANCED CLIP FUNCTION
ZEUS4-VD supports advanced CLIP (Calling Line Identification Presentation) function with
confirmation. Benefit of this CLIP function is that it that the user can control the different function
on ZEUS4-VD without any costs and receives a confirmation that the CLIP has been
acknowledged.
NOTE
To activate the advanced CLIP function call must be canceled after 1 and up to 3 rings.
CLIP function makes a call back to calling number to confirm the control.
11.3.1 TC parameters
10 telephone numbers which are stored into the phone book from TN1 to TN0 can manage
following functions using CLIP without making any cost to the user’s GSM bill. With TC
parameter you define the function you need for corresponding TN number.
 Trigger one of the ZEUS4-VD Output (parameter 1-4)
 Switch the system ON/OFF (parameter 5)
 System control with “Call-back” function (parameter 6)
NOTE
With one telephone number you can control only one function (for example trigger
only first output)!
Table of parameters:
Name
Comment
TC1
First CLIP telephone number = TN1
TC2
Second CLIP telephone number = TN2
TC3
Third CLIP telephone number = TN3
TC4
Forth CLIP telephone number = TN4
TC5
Fifth CLIP telephone number = TN5
TC6
Sixth CLIP telephone number = TN6
TC7
Seventh CLIP telephone number = TN7
TC8
Eight CLIP telephone number = TN8
TC9
Ninth CLIP telephone number = TN9
TC0
Tenth CLIP telephone number = TN0
Table 23: TC parameters
Example:
 Direct programming on the SIM card
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name
Number
Description
TC1
3
1
st
CLIP activates the Output 3
TC2
5
2
nd
CLIP switches system OFF/ON
TC3
6
3
rd
CLIP calls back from device to user
Table 24: TC parameters example
 Remote programming by SMS
;TC1=3;TC2=5;TC3=6;
