ZEUS4-VD
INSTALLATION MANUAL
33
11.7 CONTACT ID EVENT REPORTING
ZEUS4-VD is capable to send all of its events in Contact ID form to CMS. Next parameters are
used to support this function.
11.7.1 CID parameter
CID parameter is used to enable/disable this function.
11.7.2 CIN parameter
CIN parameter is used to set incoming volume level for CID communication. CIN level can vary in
range from 0 to 20.
11.7.3 COUT parameter
COUT parameter is used to set outgoing volume level for CID communication. COUT level can
vary in range from 0 to 40.
11.7.4 TN11 parameter
TN11 parameter represents primary telephone number for CID reporting.
11.7.5 TN12 parameter
TN12 parameter represents secondary telephone number for CID reporting.
Table of parameters:
Name
Comment
CID
CID function enable/disable parameter
CIN
CID incooming volume setting
COUT
CID outgoing volume setting
TN11
Primary telephone number
TN12
Secondary telephone number
Table 31: CID parameters
Example:
 Direct programming on the SIM card
ZEUS4-VD PROGRAMMING TABLE
SIM CARD PHONE BOOK
Name
Number
Description
CID
1
CID reporting enabled
CIN
12
CID incoming volume level
TN11
042340880
Primary telephone number
Table 32: CID parameters example
 Remote programming by SMS
;CID=1;CIN=12;TN11=042340880;
