11.4 CLIP FUNCTION
The second CLIP function that ZEUS4-VD supports is simple CLIP (Calling Line Identification
Presentation) function. Benefit of simple CLIP function is that it supports more user than advanced
CLIP function and is used to simply control the predefined output of ZEUS4-VD.
To activate simple CLIP function just call ZEUS4-VD device. The device will
automatically disconnect the call and control the output.
11.4.1 CLPEN parameter
Parameter is used to enable/disable simple CLIP function.
CLPEN = 0 Clip function is disabled
CLPEN = 1 Clip function will only work on numbers defined with CLP parameters
CLPEN = 2 Clip function will with ALL numbers calling ZEUS4-VD
11.4.2 CLPOU parameter
Parameter is used to define which output should ZEUS4-VD trigger if the number called the device
is on the CLP list
Trigger one of the ZEUS4-VD Outputs (parameter 1-4)
11.4.3 CLPI parameter
CLPI parameter is a precondition for simple CLIP function to operate. With this parameter user
defines the input that has to be activated for simple CLIP function to operate.
Precondition can be one of the ZEUS4-VD Inputs (parameter 1-4), with 0 this precondition
is disabled.
11.4.4 CLP1 to CLP10 parameters
The parameters are used to define telephone numbers for simple CLIP function.
