ZEUS4-VD

INSTALLATION MANUAL

19 TECHNICAL SPECIFICATIONS

Description

Value

Power Supply

13,8 - 14,7V DC

Battery backup (optional)

12V/1,2Ah

Current consumption - peak

Current consumption - transmitting mode

250mA

Current consumption - idle mode

90mA

QUAD band GSM module

850/900/1800/1900 MHz

PCB dimensions

105 × 80 mm

Unit dimensions

120 × 170 × 60 mm

Unit dimensions - IP56 box

155 × 220 × 82 mm

Antenna SMA

Weight (without battery)

550g

Alarm inputs

Alarm outputs (open collector)

ON/OFF input

12V DC Power Supply output

Backup battery input

No. of alarm SMS per unit

No. of prerecorded messages

Programmed telephone numbers

Anti-tamper protection

CLIP numbers

Event log buffer

1000

Table 37: ZEUS4-VD - Technical specifications
