Maintenance
3. Remove the filling hose and control cable from the valve cap:
4. Unscrew the valve cap:
5. Remove the valve cap from the air cannon valve. Slight turning
while lifting can help when the O-rings are dried out. Make
certain that the sealing surfaces are not damaged during the
deinstallation.
NOTE
Mark the line connection points before removal to simplify their
later reconnection.
Fig. 12
Fig. 13
