© Martin Engineering GmbH 43 M3727UK-09/15
Maintenance
Replace the removed valve by a new one as described in the
following.
Installation of the venting valve
1. Grease the O-ring and groove (1, Fig.15) liberally and insert the
O-ring into the groove. Ensure that the O-ring is cleanly inserted
into the groove and does not fall out again; a risk of damage
otherwise exists.
NOTE
Make certain that no parts fall out of the air cannon; either remove
the springs and pistons carefully or secure them against falling
out.
Fig. 14
Fig. 15
