Root Chapter 1: Description
www.masimo.com 18 Masimo
Ref.
Feature
Description
5
AC Power
Indicator
Shows an indication of AC power connection Root.
6
Radical-7
Charging
Indicator
Shows an indication of battery charge for the
Radical-7 in the Docking Station.
*Only the touchscreen version of the Radical-7 is able to communicate
monitored parameters and measurements. All other versions can only charge
in the docking station but not communicate with Root.
Back View
Feature
Description
1
Handle
Allows the user to transport Root.
2
Speaker
Provides audible notification.
3
Nurse Call Connector
Provides a connection to a Nurse Call system.
