Masimo Root RDS-7 - Chapter 8: Specifications; Electrical; Environmental

www.masimo.com 79 Masimo
Chapter 8: Specifications
This chapter contains specifications of Root.
For information on the specifications of Radical-7, MOC-9 modules, and
standalone devices, refer to their respective instructions for use or operator's
manuals.
Electrical
Root
AC Power requirements
100-240 VAC~, 47-63 Hz, 65 W (Max)
Fuses (2)
2 Amp, Fast Acting, Metric, (5x20mm), 250V
Battery
Type
10.8V Lithium Ion (Nominal)
Capacity
4 hours*
Maximum Charging Time
4 hours
*This represents approximate run time at the lowest brightness, using a fully
charged battery.
Environmental
Root
Operating Temperature
32°F to 122°F (0°C to 50°C)
Transport/Storage Temperature
-40°F to 158°F (-40°C to 70°C)
Operating Humidity
10% to 95%, non-condensing
Storage Humidity
10% to 95%, non-condensing
