Masimo Root RDS-7 User Manual

www.masimo.com 17 Masimo
Chapter 1: Description
Root can be used in the following ways:
 As a docking station and charger for Radical-7
 As a bedside monitoring display for parameters on Radical-7 and
MOC-9 modules
 As a connectivity gateway for standalone devices.
Features
Front View
Ref.
Feature
Description
1
Docking Station
Provides a docking station for the Radical-7. While
docked, the Radical-7 can communicate monitored
parameters and measurements.*
2
Root Display and
Touchscreen
Provides an interface for user interactions.
3
Home Button
Provides access to the Main Screen.
4
Root Charging
Indicator
Shows an indication of the battery charge for Root.
