Masimo Root RDS-7 User Manual

www.masimo.com 69 Masimo
Chapter 5: Iris
Iris allows a variety of standalone devices to connect to Root. Patient data
can be passed through Root to Patient SafetyNet or Connectivity Gateway,
which can send the data to electronic health records.
Below is an example of one way Root can be used in a network setting using
Patient SafetyNet. Root receives and may display information from Radical-7,
MOC-9 modules, as well as standalone devices.
Ref.
Description
1 - 4
Standalone devices connected via Iris (e.g., monitor, pump, ventilator)
5
Root
6
Radical-7
7
MOC-9 modules
8
Patient SafetyNet or Masimo Connectivity Gateway
9
Electronic Health Records system
