Masimo Root RDS-7 User Manual

Root Chapter 3: Operation
www.masimo.com 63 Masimo
Lights
System Status Lights
The System Status Lights provide visual indications of alarms and system
messages. The lights will illuminate in different colors depending on the state
of the device.
To locate the System Status Lights, see Side Views on page 19.
System Status Light
Light Status
Alarm Priority
Indication
None
None
Monitoring has not begun.
Green
None
There is currently no active alarms.
Yellow
Low
There is an active alarm of low priority.
Red
High
There is an active alarm of high priority.
The alarm priority is determined by the Radical-7 and MOC-9 module(s) that
are connected to Root. The following are system level alarm messages that
accompany System Status Lights when Radical-7 and MOC-9 modules are
not connected:
Status Light Message
Alarm Priority
Low battery
Low
Service required
High
AC Power Indicator
