Masimo Root RDS-7 User Manual

Root Chapter 3: Operation
www.masimo.com 55 Masimo
Layout
Use the Layout screen to select sizing options for Windows and Trend
Displays.
Additional Settings
There are different ways to display the parameters and measurements by
changing the Layout Style.
Note: This feature only applies to Trend View. See Using Trend View on
page 37.
Option
Description
Factory Default
Setting
Configurable
Settings
Layout
Style
Controls the sizing of
Trend Displays.
Fixed
Fixed or Dynamic
The following diagram and tables explain the differences between Fixed and
Dynamic modes for a Trend View.
