Masimo Root RDS-7 User Manual

Root Chapter 2: Setting Up
www.masimo.com 25 Masimo
To connect to a Nurse Call System
1. Identify the Nurse Call connection end (1/4 inch round female
connector) of the cable.
2. Insert the Nurse Call connection cable securely into the compatible
port on Root.
3. Depending on the connection type of the Nurse Call System, it may
be necessary to orient the other end of the Nurse Call connection
cable to fit correctly into the system connection.
4. For more information, see Device Output on page 51.

Masimo Root RDS-7 Specifications

General

Brand	Masimo
Model	Root RDS-7
Category	Measuring Instruments
Language	English
