Masimo Root RDS-7 User Manual

Root Chapter 3: Operation
www.masimo.com 30 Masimo
Ref.
Feature
Description
7
Iris
Provides access to the Iris screen. The example shown
above indicates that standalone devices are connected to
Ports 1, 2 and 3 and the information is being sent to
Patient SafetyNet or Connectivity Gateway.
The color of the icon matches the status colors of
connected standalone devices on the Iris screen. See Iris
on page 54.
8
Radical-7
Battery
Displays charging status for Radical-7 and provides
access to the Battery Radical screen. The example shows
that the battery is currently charging.
See Radical-7 Charging Indicator on page 64.
9
Root
Battery
Displays charging status for Root and provides access to
the Battery Root screen. The example shows that the
battery is currently charging.
See Root Charging Indicator on page 64.
10
Sounds
Provides access to the Sounds screen to adjust alarm and
pulse tone volume. This icon does not indicate the actual
volume level of the alarm and pulse tone.
See Sounds on page 57.
11
Current
Time
Displays the current time and provides access to the
Localization screen which contains settings related to local
time, language and geography.
See Localization on page 45.
