Masimo Root RDS-7 User Manual

Root Chapter 3: Operation
www.masimo.com 33 Masimo
Control
Applicable
Actions
Description
Press anywhere
outside spinner
When open, collapses spinner
Button
Press
Performs action (as defined by the
button description)
Icon Menu
Press tile
Opens menu specified by tile
Swipe left or right
(anywhere)
Scrolls icons left or right
Press bottom
indicator icon
Quickly centers tile corresponding to
indicator icon
Window
Press parameter or
measurement
When no parameter or measurement
alarm is present, opens parameter or
measurement menu
When parameter or measurement
alarm is present, silences parameter or
measurement alarm
Press and hold
Enables parameter and measurement
drag and drop
Well
Press parameter or
measurement
When no parameter or measurement
alarm is present, opens parameter or
measurement menu
When parameter or measurement
alarm is present, silences parameter or
measurement alarm
Press and hold
Enables parameter and measurement
drag and drop
Live
Waveform
Swipe down
Separates pleth and acoustic
waveforms
Swipe up
Combines pleth and acoustic
waveforms
