5. Detailed Component Overview
5.1. Liquid Crystal Polarization Modulator (LCPM)
Stand :
Used to adjust the height and an
gle of the LC Frame
in respect to the projector lens.
Cooling Fan
Cool Fan
Connector
Actuator Cable
Connector
Liquid Crystal Panel
LC Frame
3-Digit LED
RUN/STOP Button
Sync Cable
Connector
Power Adaptor
Jack
(DC 24V/2.5A)
Ethernet Connector
Mode
Selector
