6.4.3. Test Actuator Operation – 2D Position
Press and hold the Actuator 2D button for 1
second and release.
The Actuator will transition to the 2D
position with the 2D button LED flashing,
and the cooling fans will stop.
Once in the 2D position the 2D button LED
will be lit solid.
(Figure 17).
Figure 17. 2D Position and Button LED
Indication
