12. Appendix B MI-WAVE3D Automation
Table B-1. GPIO (37-9 pin) Automation
DSUB9(GPIO)
Comm.
Direc-
tion
DSUB37
Description
Comments
Pin name
Pin
number
Pin
number
NC
1
No connection
PRJ_COM_nRUN
2
12(+)
LCPM RUN command
Comparator
24V max,
12V threshold
(LM2901H)
5
31(-)
PRJ_SYNC
3
9(+)
Vertical sync pulse
5
28(-)
PRJ_COM_nUP
4
2(+)
LCPM 3D command
Low Pulse ≥ 200ms
5
21(-)
GND
5
20,21,22,
28,29,30,
31,
Ground
PRJ_COM_nDOWN
6
3(+)
LCPM 2D command
Low Pulse ≥ 200ms
(LM2901H)
5
22(-)
PRJ_STS_nLOCK
7
1(+)
LCPM driving status
High pulse ≥ 200ms
Open
collector
output
24V, 20mA
(SN7407)
5
20(-)
PRJ_STS_nUP
8
10(+)
LCPM position status
High pulse ≥ 200ms
5
29(-)
PRJ_STS_nDOWN
9
11
LCPM position status
High pulse ≥ 200ms
5
30
Shield ground
frame
frame
Chassis Ground Connection
