8.2.4. IMB Configuration Settings
Projector configuration settings when using an IMB (Integrated Media Block) are slightly
different; an example of this is given below for a Christie projector and a Doremi IMB. The
changes are highlighted in bold; other projector/IMB manufacturers’ configurations may
vary slightly. Contact the respective manufacturers for specific information.
Config. 1
 Input = IMB-Internal
 Data Format = 4:4:4 (RGB)
 Source File = Based on content
resolution + aspect ratio (1998x1080
Flat, 2048x858 Scope, etc.)
 Screen File = Site-specific (typically
Flat or Scope based on content)
 Use PCF = not selected (unchecked)
 Lamp File = Site-specific
 ILS File = Site-specific
 Auxiliary Lens = Site-specific –
Selected if Anamorphic Lens or WCL
needed, otherwise unselected
Config. 2
 Measured Color = Site Specific
(Create on-site)
 Target Color =
DC28_DCI_XYZE_314_351
 Color Space = Unity RGB
 Gamma = Gamma 2.6
 LUT-CLUT = Linear_9x9x9
 Scan Type = Progressive
 LD Bypass = Selected (this sends
IMB output directly to ICP. This is
required if no LD is installed)
3D Control
 Enable 3D = Selected
 3D Sync Input Mode = Use
Selected Input Port (polarity = true)
 Frame Rate N:M = 6:2
 L/R Display Sequence = Left (L1R1
L2R2)
 3D Sync Polarity = True (If left/right
eye images swapped set to Inverted)
 Dark Time = 350µS
 Output Delay = -120µS
 Phase Delay = 0
Barco Series II projectors have a pre-installed 3D configuration file for the settings required
by the MI-CLARITY3D system. It is possible to select this file rather than making fully
manual entries, but editing of Dark Time and Output Reference Delay would be required.
