Installation & Operation Manual | MI-WAVE3D
9.3.7. 2D Position
Click the [2D] button to move the actuator to the 2D position.
The color of the [3D] button will change from green to black.
The color of the [2D] button will change from black to green.
The color of the [RUN] button will change from green to black.
The indication under Status will change from ‘Running’ to ‘Ready’.
The cooling fans will stop operation and this will be displayed in the application.
Whilst the actuator is transitioning to the 2D position ‘2D_Moving’ will be displayed, when
the 2D position is reached this will change to ‘2D’.
The LCPM operation will stop and the frequency will display as 0.
