3.2.3 Rear view
The following components are located on the back panel:
1) Power cord socket
2) USB 2.0. female B type. Host socket
3) Ethernet connector with traffic LED
4) USB 2.0 port – No.1
5) USB 2.0 port – No.2
6) Rejection bin fixing slot
7) Kensington lock
3.2.4 Power supply
The printer comes with an external auto-switching power supply.
Note: Only use the power supply provided with the printer.
3.2.5 Plastic cards
Listed below are the plastic card specifications:
• Type: PVC, PVC & Composite
• Dimensions: ISO CR80 - ISO 7810 (53.98 x 85.60)
• Thickness: 0.25 to 1.25 mm (10 to 50 mil) manual gauge adjustment
• Magnetic stripe: ISO 7811
• Smart Card Contact: ISO 7816-1,2,3,4
• Smart Card Contactless: ISO 14443A/B.
