Vision System Manual
16 HH:MM:SS HH:MM:SS
17 HH:MM:SS HH:MM:SS
18 HH:MM:SS HH:MM:SS
19 HH:MM:SS HH:MM:SS
20 HH:MM:SS HH:MM:SS
21 HH:MM:SS HH:MM:SS
22 HH:MM:SS HH:MM:SS
23 HH:MM:SS HH:MM:SS
Step 4
Use following command to program relay port ‘ON’ duration timer:
3036-Seconds
Where,
Seconds is from 000 to 255.
By default, Replay port ‘ON’ duration timer is 60 seconds.
Step 5
Use following command to program relay port ‘OFF’ duration timer:
3037-Seconds
Where,
Seconds is from 000 to 255.
By default, Relay port ‘OFF’ duration timer is 60 seconds.
Step 6
Use following command to operate relay if used in total manual/Partial manual mode:
3990 : To turn OFF the relay.
3991 : To turn ON the relay.
Example:
Program Vision for following constraints:
A school wants to ring the school bell at following times:
ON Time OFF Time
07:00:00 07:00:45
07:20:00 07:20:30
08:00:00 08:00:30
08:30:00 08:30:30
09:00:00 09:00:30
09:30:00 09:30:45
10:15:00 10:15:45
10:45:00 10:45:30
11:15:00 11:15:30
11:45:00 11:45:30
12:15:00 12:15:45
Issue following commands:
1801-7
1802-1-00-070000
1802-1-01-072000
1802-1-02-080000
