Matrix
164
Vision System Manual
How to program?
Step 1: Decide the number of station groups to be formed, decide the sequence in which the stations should
be arranged. Program these parameters using command 4702.
Step 2: Define ring timer for which each station should ring using command 4703.
Step 3: Decide whether the station should get continuous ring and program it using command 4704.
Step 4: Program the rotation type for the station group using command 4705.
Step 5: It is possible to default a station group using command 4701.
Each group entry in the station group table looks like:
Dest0
Dest1 Dest2 Dest3
Station Number
Ring Timer
Continuous Ring
Rotation Method
Yes or No
Step 1
Use following command to program station group:
4702-1-Station Group-Destination Index-Station
Where,
Station Group is from 00 to 15.
Destination Index is from 0 to 3.
Station is a software port number is from 00 to 08.
Use following command to program same station for all station groups:
4702-*-Destination Index-Station
Step 2
Use following command to program the time for which each station in the group should ring:
4703-1-Station Group-Destination Index-Timer
Where,
Station Group is from 00 to 15.
Destination Index is from 0 to 3.
Timer is in seconds from 00 to 99.
Use following command to program the ring timer for stations with same destination index for all the station
groups:
4703-*-Destination Index-Timer
Step 3
Use following command to program continuous or non-continuous ring for a destination in the group:
4704-1-Station Group-Destination Index-Continuous Ring
Where,
Station group is from 00 to 15.
Destination Index is from 0 to 3.
Continuous Ring
Continuous Ring Meaning
0 The station rings for the time set
1 The station rings till the call matures
Use following command to program continuous or non-continuous ring for stations with same destination index
in all the station groups:
4704-*-Destination Index-Continuous Ring
