Vision System Manual
187
Matrix
piece of paper and make corresponding allowed lists and denied lists using step 6 and step 7.
Step 6 and Step 7
Please refer “Allowed List and Denied List”.
Step 8 and Step 9
Please refer step 3 and step 4 explained above.
Step 10
Use following command to assign allowed list to a station for locked condition:
4521-1-Station-Locked Allowed List
Where,
Station is the software port number of the user from 00 to 08.
Locked Allowed List is from 0 to 7.
Use following command to assign allowed list to all stations for locked condition:
4521-*-Locked Allowed List
Step 11
Use following command to assign denied list to a Station for locked condition:
4522-1-Station-Locked Denied List
Where,
Station is the software port number of the user from 00 to 08.
Locked Denied List is from 0 to 7.
Use following command to assign denied list to all Stations for locked condition:
4522-*-Locked Denied List
Step 12
Please refer “Configuration Report”.
Example:
Let us program the system for following conditions:
We have two station users 21 and 22 (software port number 00 and 01)
For 21: During daytime: Allow 011-6565655 and 011-6565656 but restrict all other 011 calls. Allow all 022 calls
but restrict 022-7878787 and 022-7878788. Allow all local calls and other long distance calls. Restrict
all calls during night time.
For 22:Allow all calls except ‘0’ calls during daytime. Restrict all calls during night time.
Solution:
It is advisable to make changes for any customized requirement in allowed list 6 & 7 and denied list 6 & 7 so
that default lists can be assigned to other stations without making any changes. Let us make an allowed list 6
which shall allow 011-6565655, 011-6565656, 022,0,1,2,3,4,5,6,7,8 and 9. Let us make a denied list 6 which
shall restrict 022-7878787, 022-7878788 and 011 but shall allow all other calls.
Use following command to program allowed list 6:
1202-1-6-00-0116565655-#*
1202-1-6-01-0116565656-#*
1202-1-6-02-022-#*
Other location in the allowed list are blank and hence other numbers like 0,1,2,3,4,5,6,7,8 and 9 need not be
entered.
