Matrix Vision User Manual

Matrix
192
Vision System Manual
How to program?
Step 1: Decide number of Trunk Access Groups to be formed. Program these groups using command 4402.
Step 2: Program rotation code to select a trunk within the trunk access group using command 4403.
Step 3: Set a Trunk Access Group to default settings using command 4401 (if required).
Step 4: Assign a trunk access group and a trunk access code to a station for day time.
Step 5: Assign a trunk access group and a trunk access code to a station for night time.
Step 1
Use following command to put trunks in a trunk access group:
4402-1-Trunk Access Group-Trunk0.....Trunk2/#
Where,
Trunk Access Group is from 0 to 7.
Trunk0..Trunk2 are the software port numbers of the trunks from 0 to 2.
Use following command to put same trunks in all trunk access groups:
4402-*-Trunk0....Trunk2/#
Trunk Access
Group
Trunk allowed
Trunk Access Code (both
daytime and nighttime)
0 0, 1, 2 0 and 5
10 61
21 62
3 2 No code assign
4 No trunk No code assign
5 No trunk No code assign
6 No trunk No code assign
7 No trunk No code assign
Step 2
Use following command to program rotation code for a group:
4403-1-Trunk Access Group-Rotation Code
Where,
Roatation Code Meaning
0
Trunk rotation OFF within the
g
roup, s
y
stem alwa
y
s
selects the first trunk from the
g
rou
p
1 Trunk rotation ON within the group
Use following command to program same rotation code for all the groups:
4403-*-Rotation Code
By default, Trunk Rotation is ON within the group.
Step 3
Use following command to default a trunk access group:
4401-1-Trunk Access Group-#
Where,
Trunk Access Group is from 0 to 7.
Use following command to default all trunk access groups:
4401-*-#
Step 4
Vision offers maximum 4 trunk access codes viz. 0, 5, 61 and 62. These codes are common for all the station
