users. A default trunk access codes table is given below:
Trunk Access Group Index Trunk Access Code
00
15
261
362
Use following command to assign a trunk access group and trunk access code to a station for daytime:
4411-1-Station-Trunk Access Group Index-Trunk Access Group
Where,
Station is from 00 to 08.
Trunk Access Group Index is from 0 to 3.
Trunk Access Group is from 0 to 7.
Use following command to assign trunk access group and trunk access code to all the stations for daytime:
4411-*-Trunk Access Group Index-Trunk Access Group
By default, all trunks are allowed to all stations.
Step 5
Use following command to assign a trunk access group and trunk access code to a station for nighttime:
4412-1-Station-Trunk Access Group Index-Trunk Access Group
Where,
Station is from 00 to 08.
Trunk Access Group Index is from 0 to 3.
Trunk Access Group is from 0 to 7.
Use following command to assign a trunk access group and trunk access code to all the stations for nighttime:
4412-*-Trunk Access Group Index-Trunk Access Group
Trunk Access
Group
Trunk allowed
Trunk Access Code (both
daytime and nighttime)
0 0, 1, 2 0 and 5
10 61
21 62
3 2 No code assign
4 No trunk No code assign
5 No trunk No code assign
6 No trunk No code assign
7 No trunk No code assign
By default, all trunks are allowed to all stations.
Example:
Program the system for following constraints:
• 3 trunks.
• 3 departments: Technical, Marketing and Administration.
• Technical department should get access to trunk 0 and 1 during day time by dialing ‘0’.
• Marketing department should get access to trunk 1 and 2 during day time by dialing ‘0’.
• Administration department should get access to all the three trunks during day time by dialing ‘0’.
• Security station (station 29) should not get access to any trunk during day time.
• Technical department and Marketing department should not get trunk access to any trunk during night time.
• Administration department should get access to trunk 1 by dialing ‘0’ during night time.
• Station 29 (security station-software port 08) should get access to all the trunks by dialing ‘0’ during night
