Vision System Manual
time only.
• Technical department has two stations 21 and 22 (software ports 00 and 01).
• Marketing department has two stations 23 and 24 (software ports 02 and 03).
• Administration department has four stations 25, 26, 27 and 28 (software ports 04, 05, 06 and 07).
Solution:
4402-1-0-0-1-#
4402-1-1-1-2-#
4402-1-2-1-2-3-#
4402-1-3-#
4402-1-4-1-#
4411-1-00-0-0
4411-1-01-0-0
4411-1-02-0-1
4411-1-03-0-1
4411-1-04-0-2
4411-1-05-0-2
4411-1-06-0-2
4411-1-07-0-2
4411-1-08-0-3
4411-1-08-1-3
4411-1-08-2-3
4411-1-08-3-3
4412-1-00-0-3
4412-1-01-0-3
4412-1-02-0-3
4412-1-03-0-3
4412-1-00-1-3
4412-1-01-1-3
4412-1-02-1-3
4412-1-03-1-3
4412-1-00-2-3
4412-1-01-2-3
4412-1-02-2-3
4412-1-03-2-3
4412-1-00-3-3
4412-1-01-3-3
4412-1-02-3-3
4412-1-03-3-3
4412-1-04-0-1
4412-1-05-0-1
4412-1-06-0-1
4412-1-07-0-1
4412-1-08-0-2
