• Third line should land on station 28 and 29 simultaneously (S/w port 07 and 08 respectively) during day time
and night time.
• CO3 should ring continuously on both the stations.
Use following commands:
Make Group 0 as per the requirement:
4702-1-00-0-00
4702-1-00-1-02
4702-1-00-2-04
4702-1-00-3-01
4703-1-00-0-10
4703-1-00-1-10
4703-1-00-2-10
4703-1-00-3-10
4704-1-00-0-0
4704-1-00-1-0
4704-1-00-2-0
4704-1-00-3-0
4705-1-00-0
Make Group 1 as per the requirement:
4702-1-01-0-00
4702-1-01-1-00
4702-1-01-2-00
4702-1-01-3-00
4703-1-01-0-10
4703-1-01-1-10
4703-1-01-2-10
4703-1-01-3-10
4704-1-01-0-1
4704-1-01-1-1
4704-1-01-2-1
4704-1-01-3-1
4705-1-00-0
Make Group 2 as per the requirement:
4702-1-02-0-07
4702-1-02-1-08
4702-1-02-2-07
4702-1-02-3-08
4703-1-02-0-10
4703-1-02-1-10
4703-1-02-2-10
4703-1-02-3-10
4704-1-02-0-1
