Vision System Manual
Use following command to program the Programming Confirmation Tone Timer:
3008-Seconds
Range = 001 to 255 seconds.
Default = 003 seconds.
Tone Specifications:
Name Fre
q
uenc
y
Cadence
Dial Tone 512Hz Continuous
Ring Back Tone 512Hz 400ms on, 200ms off, 400ms on, 2000ms off
Busy Tone 512Hz 750ms on, 750ms off
Error Tone 512Hz 250ms on, 250ms off
Internal Call Waiting Tone 512Hz 50ms on, 2950ms off
Trunk Call Waiting Tone 512Hz 10ms on, 50ms off, 50ms on, 2850ms off
Feature Confirmation Tone 512Hz 50ms on, 50ms off
Programming Tone/Feature Tone 512Hz 100ms on, 900ms off
Programming Confirmation tone 512Hz 50ms on, 50ms off
Programming Error tone 512Hz 250ms on, 250ms off
=X=X=
